Soft loop eye: a terminal loop eye for sewing webbing components, which can be threaded by ropes and used to connect movable end fittings or connectors to the hook, other lifting equipment, or lifting parts of a crane.
When the length of the inner ring of the eye is placed flat, it should be measured with a steel tape measure or steel ruler with a division value of 1mm. The minimum size should meet the following requirements:
1. When the width of the ribbon is not greater than 150mm, it is three times the width;
2. When the width of the ribbon is greater than 150mm, it is 2.5 times the width.
Note 1: Folding eyelets are formed by folding a portion of the webbing and sewing the two sides of the webbing together or to the webbing itself.
Note 2: Folding eyelets can also be flipped.
Note 3: The types of eye rings shown in the diagram do not represent all types.
Note 4: For clarity, the reinforcement of the ring eye is omitted in the diagram, but the reinforcement of the ring eye is also a requirement of this section
Reinforcement of Soft Ring Eye
The soft eye of the lifting belt should be reinforced to prevent damage to the internal surface of the eye during lifting and hoisting.
Note: Materials suitable for reinforcement include sleeves, a piece of woven tape, leather, or other wear-resistant materials.
